Cables and wiring harnesses in the field of medical equipment have extremely high testing requirements, such as ECG, EMG signal acquisition, ultrasound, endoscope cables, in addition to high requirements for insulation leakage testing, but also for multilateral capacitance testing of cables. DP5000-C cable harness tester is a medical wiring harness and medical cable tester specially developed for medical cables, which supports the test of high insulation and leakage under low voltage test conditions, and supports the test of multilateral capacitance of shielded cables.
Performance and benefits
- Anti-high humidity environment
- Support two-wire and four-wire mixed test
- High-precision four-wire test
- Min.resolution 1Μω
- Multi-side capacitance test of medical cables
- Capacitance test stability, resolution 0.1pF
- Capacitance test frequency: 50Hz/60Hz/100Hz/120Hz/1kHz, 10kHz/50kHz
- Test leakage and insulation resistance can be tested within 0~10V
- Quality analysis, MES docking, report printing
